PRODUCTS

chenglongwei

--------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------

CLQ5090TPB

Product description

The main technical performance parameters:

Product name:

CLQ5090TPB

Dimensions:

7950×2500×2730(mm)

Chassis Type:

EQ1090LJ8BDE

Cargo Size:

××(mm)

Total mass:

9400 (kg)

Approach / departure angle:

21.5/9(°)

Rated quality:

4345(kg)

Front suspension / Rear suspension:

1180/2420(mm)

Curb weight:

4860(kg)

Top speed:

103(km/h)

Engine model

Engine manufacturer

Displacement(ml)

Power(kw)

CY4SK251
YC4S150-50
ISF3.8s5154

Dongfeng Chaoyang Chai Chai Power Co., Ltd.
Guangxi Yuchai Machinery Co., Ltd.
Beijing Futian Cummins Engine Co., Ltd.

3856
3767
3760

115
110
115

Emission Standards:

GB17691-2005 National Ⅴ, GB3847-2005

Number of axes:

2

Front track:

1745(mm)

Wheelbase:

4400(mm)

Rear track:

1640(mm)

Rated passenger

GB17691-2005 National Ⅴ, GB3847-2005 (people)

Vehicle Identification Number

LGDXUA1P×××××××××

Fuel type:

Diesel

Number of springs:

8/10+7

Axle load:

3400/6000

Front passenger

3(人)

Other:

The car is only used to transport non-dismantlable objects. With the optional chassis cab (optional front cover, front bumper, front combination of lamps); protective material: Q235A carbon steel, connection: left and right side of the plate with a welded connection, the rear slope and rear protective interference, so the rear protection Exemption. ABS Model: ABS / ASR-24V-4S / 4M, ABS Model Manufacturer: Yangyang Dongfeng Long Cheng Machinery Co., Ltd. Engine CY4SK251, YC4S150-50, ISF3.8s5154 engine, the corresponding fuel consumption values were (L / 100km) 20.0,20.6,21.0.
