Dongfeng 3.2ton truck mounted crane
Payment term: T/T, L/C , D/P
Delivery time: 15 Working days since get the Down payment.
After-sales service: For 1 year since leave factory
Shipping way: By container, RORO, Break bulk ship
Classification:
Share
Describe
| Item | Dongfeng 3.2ton truck mounted crane |
| Overall dimensions | 5995x1980x2950mm |
| Wheelbase | 3308 mm |
| GVW | 4495 KGS |
| Rated load | 1495 KGS |
| Kerb weight | 2870 KGS |
| Engine | Cummins engine,140hp, Diesel |
| Emission | Euro 3, 4, 5, 6 |
| Transmission | Manual, 6 Forward speed+ 1 Reverse |
| Tire | 7.00R16, 6+1 |
| Steering | LHD/RHD |
| Box length | 3600mm |
| Crane |
3.2Ton, XCMG brand,SQS68, Lifting height: 9.5meters, Working radius: 7.5meters, Full hydraulic |
| Option | Hydraulic single chamber or double chamber rear leg. |
